Aten CS1794
4-Port HDMI USB KVM Switch with Audio and USB 2.0 Hub
Pictures may differ from actual products
Combining a 4-port switch and a 2-port USB 2.0 hub, the CS1794 switch allows easy switching of HDMI signals between up to 4 computers or other HDMI devices, such as gaming consoles.
4-Port HDMI USB KVM Switch with Audio and USB 2.0 Hub
Overview
CS1794: 4-Port HDMI USB KVM Switch with Audio and USB 2.0 Hub (KVM cables included)
With its unique design and innovative features, the CubiQ CS1794 USB 2.0 HDMI KVMP Switch offers both style and functionality for today's small office or home office (SOHO). Combining a 4-port switch with a 2-port USB 2.0 hub, the CS1794 switch enables easy switching of HDMI signals between up to 4 computers or other HDMI devices, such as gaming consoles, and allows users to share USB devices from a single console.
The CS1794 switch provides enhanced independent switching via front panel push buttons and keyboard shortcuts and features DynaSync video technology to ensure that the HDMI display resolution is always optimal. With its integrated digital audio system, the CS1794 switcher also allows users to enjoy high-definition audio, such as Dolby True HD and DTS HD Master Audio.
Ideal for multimedia applications in the home or office environment, the CS1794 CubiQ Switch is the ultimate in space-saving and simplified KVM technology for the desktop.
With its unique design and innovative features, the CubiQ CS1794 USB 2.0 HDMI KVMP Switch offers both style and functionality for today's small office or home office (SOHO). Combining a 4-port switch with a 2-port USB 2.0 hub, the CS1794 switch enables easy switching of HDMI signals between up to 4 computers or other HDMI devices, such as gaming consoles, and allows users to share USB devices from a single console.
The CS1794 switch provides enhanced independent switching via front panel push buttons and keyboard shortcuts and features DynaSync video technology to ensure that the HDMI display resolution is always optimal. With its integrated digital audio system, the CS1794 switcher also allows users to enjoy high-definition audio, such as Dolby True HD and DTS HD Master Audio.
Ideal for multimedia applications in the home or office environment, the CS1794 CubiQ Switch is the ultimate in space-saving and simplified KVM technology for the desktop.
Key Features :
- 4-port USB HDMI KVMP switch
- One USB console controls four HDMI computers and two additional USB devices
- Built-in 2-port USB 2.0 hub , fully compatible with USB 2.0 specifications
- Independent selection of KVM control, USB devices and audio control via front panel push buttons and keyboard shortcuts
- HDMI digital monitor support: fully compatible with HDMI standard; also HDCP compliant
- Support for Dolby True HD and DTS HD MasterAudio
- Superior video quality: supports 480i, 480p, 720p, 1080i and 1080p (HDTV) / 1920 x 1200 (DVI) resolutions
- Power-on device detection: if one computer is turned off, the CS1794 switch automatically switches to the next powered-on computer
- Support for widescreen resolutions
- Multi-platform support: Windows, Linux and Mac
- Console mouse port emulation/omission is supported with most mouse drivers and multi-function mice
- Video DynaSync: saves EDID (Extended Display Identification Data) from the console monitor to optimise display resolution
- Full keyboard and mouse emulation for error-free startup
- Mac keyboard support and emulation
- Auto-switching mode to monitor all computers and HDMI devices
- Firmware upgradeability
PC keyboard combinations allow emulation of Mac keyboards / Mac keyboards only work with their own computers.
Specifications
Select your criteria
General information |
Product name |
Aten CS1794 |
Brand |
Aten | |
Model |
CS1794 | |
Technical specifications |
Product type |
KVM switch |
Connector(s) |
6 X 3.5mm Jack Female Stereo | |
| 6 X Microphone (3.5mm Jack Female) | ||
| 6 X USB Type A Female | ||
| 4 X USB Type B Female | ||
| 5 X HDMI Female | ||
Number of computers |
4 | |
Number of cable kits supplied |
4 | |
Switching method |
Buttons | |
Rackable |
No | |
Video output(s) |
HDMI | |
Peripheral input(s) |
USB | |
Network port (RJ45) |
No | |
Audio function |
Yes | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
See all Aten products
See Aten KVM section
Product referenced on 31 Aug 2015
