TheNH-L9i chromax black is the "full black" version of the popular Noctua NH-L9i ultra-compact CPU fan for HTPCs and SFFs (Small Form Factor). With the same proven design and NF-A9x14 PWM fan, this model maintains the NH-L9i's level of excellence by combining a height of only 37 mm, a very good level of performance and silence as well as full compatibility with memory and PCIe slots. The chromax.black version offers an elegant and sober look thanks to the black radiator cover and the black fan. Supplied with the popular SecuFirm2 compact multi-socket mounting system for LGA115x, Noctua NT-H1 thermal paste and backed by a full 6-year manufacturer's warranty, the NH-L9i chromax black is the perfect premium choice for those looking for an ultra-compact cooler that looks as good as it works.
The NF-A9x14 fan features a highly optimised AAO frame for outstanding aerodynamic performance. With PWM support, the NF-A9x14 keeps the NH-L9i surprisingly quiet.
The NH-L9i comes with a custom SecuFirm2 system for LGA115x without a backplate. This feature further improves compatibility with mini-ITX motherboards and makes installation easier than ever.
Select your criteria
General information |
Product name |
Noctua NH-L9i Chromax Black |
Brand |
Noctua | |
Model |
NOCTUA NH-L9I CH.BK | |
Technical specifications |
Use |
Processor |
Processor support |
Intel 1150 | |
| Intel 1151 | ||
| Intel 1155 | ||
| Intel 1156 | ||
| Intel 1200 | ||
Color |
Black | |
Luminous |
No | |
Connector(s) |
4-pin Female | |
Ball bearing |
No | |
PWM |
Yes | |
Heat Pipe |
Yes | |
Adjustable speed |
Yes | |
Cooling type |
Ventirad (active) | |
Top Flow |
Yes | |
Dual tower |
No | |
Fan diameter |
92 mm | |
Min sound level |
14.8 dB | |
Max sound level |
23.6 dB | |
Minimum rotation speed |
300 RPM | |
Maximum rotation speed |
2500 RPM | |
Min airflow |
40.8 m³/h | |
Max airflow |
57.5 m³/h | |
Material(s) |
Aluminum | |
| ABS (Plastic) | ||
| Copper | ||
Use |
Office | |
| Multimedia | ||
AIO radiator compatibility |
N/A | |
Dimensions |
Height (fan included) |
37 mm |
Width (fan included) |
95 mm | |
Depth (fan included) |
95 mm | |
Height |
23 mm | |
Width |
95 mm | |
Depth |
95 mm | |
Weight |
420 g | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
See all Noctua products
