MSI Cubi NUC 1M-026BEU.
Barebone Intel Core 3 100U Wi-Fi 6E/Bluetooth (without screen/memory/hard drive/system).
Pictures may differ from actual products
The MSI Cubi NUC 1M is an ideal barebone for professionals and home users looking for power in a compact format. With a chassis weighing in at just 0.826 litres, it's designed to save space without sacrificing performance.
Barebone Intel Core 3 100U Wi-Fi 6E/Bluetooth (without screen/memory/hard drive/system).
Cubi NUC : High-performance barebone with durable design
The MSI Cubi NUC 1M is an ideal barebone for professionals and home users looking for power in a compact format. With a chassis of just 0.826 litres, it's designed to save space without compromising on performance.
The MSI Cubi NUC 1M-026BEU is powered by an Intel Core 3 100U processor, with the addition of DDR5 in SO-Dimm format and an M.2 NVMe SSD.
The Cubi NUC 1M is upgradeable, so it has several storage options, including two M.2 slots for NVMe PCIe 4.0 x4 SSDs and one slot for a 2.5" hard drive. As for RAM, it can accommodate up to 64 GB of DDR5. As for connectivity, the Cubic NUC 1M supports up to 4 monitors simultaneously, offers 4 USB 3.1 ports and full wired and wireless network connectivity.
Key features
- Compact design with a chassis weighing just 0.826 litres, saving space on your desk.
- High-performance thanks to its 12th-generation Intel Core processor for smooth, enjoyable operation, suitable for multitasking and demanding applications.
- Scalable with support for up to 64 GB of DDR5 memory
- Numerous storage options with 2 M.2 NVMe PCIe 4.0 x4 slots and a 2.5" bay.
- Rich connectivity with 4 x USB 3.1 10 Gbps ports, 2 x HDMI 2.1 and 2 x Thunderbolt 4
- State-of-the-art networking with 2 x 2.5 GbE LANs and Wi-Fi 6E/Bluetooth 5.3 wireless connectivity
- Compatible with VESA100 for mounting behind a compatible monitor or on a wall.
Sustainable design
- EPEAT certification, the world's first eco-label for electronics.
- The Cubi NUC mini PC contains 42.9% PCR plastic (Post-Consumer Recycled Plastics), reducing plastic waste sent to landfill and helping to preserve the environment.
- Cardboard packaging made from wood pulp from sustainable, FSC-certified sources. This certification guarantees that the materials are renewable and low-carbon, promoting environmental sustainability.
Key features :
- Intel Core 3 100U processor (2 Performance-Cores 1.2 GHz / 4.7 GHz Turbo + 4 Efficient-Cores 0.9 GHz / 4.7 GHz Turbo - 8 Threads - 10 MB Cache)
- DDR5 SO-DIMM 5200 MHz (2 slots - maximum 64 GB)
- 2 M.2 PCIe 4.0 x4 slots + 1 2.5" SATA 6 Gbps bay
- Two 2.5 GbE LANs
- Wireless connectivity Wi-Fi 6E + Bluetooth 5.3
- Video outputs: 2x HDMI 2.1 + 2x Thunderbolt 4, one of which is Power Delivery compatible up to 100 Watts
- Can be mounted on VESA 100 x 100 mm
- Windows 11 Professional
Select your criteria
General information |
Product name |
MSI Cubi NUC 1M-026BEU. |
Brand |
MSI | |
Model |
936-B0B111-026 | |
Processor and chipset |
Integrated processor |
Yes |
Processor |
Intel Core 3 | |
CPU frequency |
1.2 GHz | |
Number of CPUs supported |
1 | |
Memory |
Memory format |
2 X SO-DIMM 262-pin (DDR5) |
Memory Frequency(ies) |
DDR5 5200 MHz | |
Memory type |
DDR5 | |
Memory technology |
Dual Channel | |
Dual Channel |
Yes | |
Maximum RAM capacity per slot |
32 GB | |
Maximum RAM capacity |
64 GB | |
Graphic |
Integrated graphics controller |
Yes |
Graphics chipset |
Intel Graphics | |
Expansion slots |
Graphic connector(s) |
None |
Storage |
Hard drives connectors |
1 X Serial ATA 6Gb/s (SATA Revision 3) |
| 2 X M.2 - PCI-E 4.0 x4 | ||
M.2 support |
1 X M.2 2242 | |
| 1 X M.2 2280 | ||
Network |
Number of ports/Ethernet controler |
2 X Intel i226-V |
Network standard(s) |
2.5 Gbps Gigabit Ethernet (2.5 GbE) | |
Wireless network standard(s) |
Wi-Fi 6E | |
| Bluetooth 5.3 | ||
Connectivity |
Front panel connectors |
1 X 3.5mm Jack Female Stereo |
| 2 X USB 3.1 | ||
Rear panel connectors |
2 X RJ45 Female | |
| 2 X HDMI Female | ||
| 2 X USB 3.1 | ||
| 2 X Thunderbolt 4/USB-C | ||
| micro SD | ||
Case |
Number of 2.5" slots |
1 |
Power |
120 W | |
Compatibility |
Supported OS |
Microsoft Windows 11 |
Physical characteristics |
Barebone format |
Mini PC |
Width |
132.5 mm | |
Height |
50.1 mm | |
Depth |
135.6 mm | |
Weight |
625 g | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
See all MSI products
Product referenced on 22 Aug 2024
