Intel NUC 13 Extreme RNUC13RNGI70002
Intel Core i7-13700K Wi-Fi 6E/Bluetooth - 10 GbE LAN + 16x PCI-E 4.0 / PCI-E 5.0 M.2 slots (without display/memory/hard drive/system)
Last price 1 549€94Design an ultra-powerful Mini Gaming PC
TheIntel NUC 13 Extreme NUC13RNGi7 is a barebone with powerful components ideal for designing a compact, high-performance gaming PC. It features a 13th generation Intel Core i7 processor and can support up to 64GB of DDR5 RAM, PCI-E 4.0 NVMe M.2 SSDs and a 16x PCI-Express 5.0 Triple Slot graphics card (up to 313mm in length and 450W max.).
Incredible performance
With its 13th generation Intel Core processor, the Intel NUC offers both outstanding performance and low power consumption. The 13th generation Intel Core processors are packed with advanced features to enhance entertainment quality and gaming performance.
The NUC 13 Extreme also offers Wi-Fi 6E, 10 GbE and 2.5 GbE networking and two Thunderbolt 4/USB-C ports.
Compatible with standard graphics cards
TheIntel NUC 13 Extreme is capable of hosting a standard PCI-Express 16x graphics card (Triple Slot and up to 313mm in length). This will allow you to build a compact gaming PC capable of incredible gaming performance. The SFX 750W 80+ Gold power supply also features 3 x 6+2 PCI-Express connectors.
General information |
Product name |
Intel NUC 13 Extreme RNUC13RNGI70002 |
Brand |
Intel | |
Model |
RNUC13RNGI70002 | |
Processor and chipset |
Integrated processor |
Yes |
Processor |
Intel Core i7 | |
CPU frequency |
3.4 GHz | |
Processor support |
N/A | |
Number of CPUs supported |
1 | |
Chipset |
Intel Z690 Express | |
Memory |
Memory format |
2 X SO-DIMM 262-pin (DDR5) |
Memory Frequency(ies) |
DDR5 5600 MHz | |
Memory type |
DDR5 | |
Memory technology |
Dual Channel | |
Dual Channel |
Yes | |
Maximum RAM capacity per slot |
32 GB | |
Maximum RAM capacity |
64 GB | |
Graphic |
Integrated graphics controller |
Yes |
Graphics chipset |
Intel UHD Graphics 770 | |
Expansion slots |
Graphic connector(s) |
1 X PCI Express 5.0 x16 |
Graphic card max. length |
313 mm | |
Storage |
Hard drives connectors |
2 X M.2 - PCI-E 4.0 x4 + SATA 6 Gb/s |
1 X M.2 - PCI-E 4.0 x4 | ||
M.2 support |
M.2 2280 | |
M.2 2242 | ||
Supported RAID Modes |
0 | |
1 | ||
Optical drive type |
None | |
Audio |
Audio Chipset |
Integrated |
Number of audio channels |
8 | |
Network |
Number of ports/Ethernet controler |
1 X AQUANTIA 10 GbE |
Number of ports/Ethernet controler N°2 |
1 X Intel i226-V | |
Network standard(s) |
2.5 Gbps Gigabit Ethernet (2.5 GbE) | |
10 Gbps Gigabit Ethernet (10 GbE) | ||
Wireless network standard(s) |
Bluetooth 5.2 | |
Wi-Fi 6E | ||
Connectivity |
Front panel connectors |
1 X 3.5mm Jack Female Stereo |
1 X USB 3.1 Type C | ||
2 X USB 3.0 | ||
Rear panel connectors |
2 X RJ45 Female | |
6 X USB 3.1 | ||
2 X Thunderbolt 4/USB-C | ||
1 X HDMI Female | ||
Case |
Number of 2.5" slots |
0 |
Number of invisible 3.5" slots |
0 | |
Number of visible 3.5" slots |
0 | |
Number of visible 5.25" slots |
0 | |
Number of invisible 5.25" slots |
0 | |
Number of Slot-in slim 5.25'' slots |
0 | |
Number of Slim 5.25'' slots |
0 | |
Power |
750 W | |
Compatibility |
Supported OS |
Windows 11 Pro |
Windows 11 Home | ||
Max CPU TDP |
125 W | |
Physical characteristics |
Barebone format |
Mini PC |
Width |
129 mm | |
Height |
337 mm | |
Depth |
318 mm | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
