QNAP TVS-472XT-PT-4G

4-bay NAS server (without hard drive) with 4GB DDR4

Last price 1 582€94
Holy Moly!
Overview

State-of-the-art performance and connectivity with 10GbE, Thunderbolt 3 and M.2 NVMe PCIe SSD slots


Powered by an 8th generation Intel Pentium Gold processor, the high-performance TVS-472XT NAS features high-speed 10GBASE-T and Thunderbolt 3 connectivity to handle heavy workloads and smoothly transfer, display, and edit 4K video in real time. With support for M.2 SSDs and the ability to install a graphics card, the TVS-472XT offers the ability to boost performance and create a scalable work environment for high-speed collaboration and file sharing. The TVS-472XT is equipped with high quality hardware that delivers optimal performance, full multimedia capabilities, expandable storage capacity and many other NAS features to inspire more creativity and achievement!
  • High-speed Thunderbolt 3 with SMB protocol, allowing Mac and Windows users to collaborate on multimedia editing.
  • RJ45 10GBASE-T 5-speed connectivity accelerates virtualization applications and file sharing between teams and devices.
  • PCIe expandability allows you to use an entry-level graphics card to speed up NAS video processing and GPU computation.
  • Install PCIe M.2 NVMe SSDs (Gen 3 x2, 2GB/s) (sold separately) to set up cache or storage pools, improving file access efficiency.
  • 4K playback and real-time transcoding; display creative work directly on an HDTV via HDMI 2.0 output (4K at 60Hz).
  • Snapshots record the entire system and data status, allowing you to protect your data and files from accidental deletion and malware attacks.


Fast and flexible Thunderbolt 3 and 10GBASE-T connectivity


The TVS-472XT adopts the powerful 8th generation Intel Pentium Gold G5400T 3.1GHz dual-core processor with 4GB of dual-channel DDR4 memory (expandable up to 32GB) to deliver exceptional performance. It offers two Gigabit ports and a 5-speed 10GBASE-T port (10G/5G/2.5G/1G/100M), supports SATA 6Gb/s drives, and includes AES-NI encryption to deliver high performance while keeping your data safe. You can also connect USB Type C devices via the Thunderbolt 3 ports to transfer large media files between devices, providing a more efficient workflow.


Get more performance with M.2 SSD cache


In addition to using 2.5-inch SSDs for caching, you can use the two M.2 SSD slots built into the TVS-472XT to integrate NVMe PCIe SSDs (Gen 3 x2, 2GB/s) with 2280 form factors (M.2 SSDs sold separately).

SSD caches accelerate IOPS performance and reduce storage volume latency. They are ideal for IOPS-intensive applications (including databases and virtualisation) and can significantly improve overall workflows.
Qtier technology enhances the TVS-472XT with automatic tiering that helps continuously optimise storage efficiency by automatically moving data between M.2 SSDs, 2.5-inch SSDs, and high-capacity hard drives based on data access frequency. Qtier 2. 0 includes I/O recognition that prioritizes SSD storage with reserved space as a cache to manage burst I/O in real time, greatly maximizing the benefits of SSDs.


Achieve performance and endurance levels potentially similar to professional SSDs


With SSD prices becoming more affordable, now is the best time to use SSDs in your NAS to enjoy superior performance, faster file backups, smoother multimedia experiences, and optimized virtualization applications. Starting with QTS 4.3.5, you can take advantage of the additional overprovisioning (OP) in RAID SSDs that allows you to allocate additional OP space (from 1 to 60%) to optimize random write speeds and increase SSD life. Now you can use affordable consumer SSDs for the TVS-472XT, set the SSD OP, and potentially achieve performance and endurance levels similar to professional SSDs.


Flexibly manage virtual and physical networks


The Virtual Switch and Network app manages physical network interfaces (including network adapters and Thunderbolt ports) and virtual adapters (virtual machines and containers) and their communications, providing a visualized topology that clearly shows physical and virtual network connections. The flexible management capability allows you to more easily rearrange physical and virtual network connections, so you can allocate adequate network resources to the TVS-472XT, virtual machines and containers as needed.


Collaboration Station for Mac and Windows


The TVS-472XT isideal for Mac and Windows users with Thunderbolt - especially photographers, film makers and graphic designers who need 4K media storage, instant sharing and high-speed workflows. Up to 2 Thunderbolt devices can be connected to the TVS-472XT to handle simultaneous photo and audio editing without affecting system performance. Since Final Cut Pro X 10.3 (and later) supports file sharing via SMB, Windows users and other devices using Thunderbolt 3, 10GbE or GbE connections can join the editing workflow more efficiently.


The best storage solution for 10GbE-equipped iMac Pros


The iMac Pro is the first Mac computer to include a 10GbE Ethernet port, setting a milestone in the growing consumer demand for 10GbE connectivity. Since the TVS-472XT comes with both 10GbE and Thunderbolt 3 ports, it offers an exceptional storage foundation for iMac Pro users as they can choose between Thunderbolt 3 and 10GbE connections to suit the needs of their applications and devices.


Ultimate visual experience with 4K HDMI output


The TVS-472XT features an HDMI 2.0 port that supports 4K (3840 x 2160) output at 60Hz. This provides exceptional benefits for applications such as video production/editing, industrial design and professional photography that require high display resolution and colour realism as well as huge media storage, transfer and display capabilities. By connecting the TVS-472XT to an HDTV receiver via the HDMI output, you can directly display the multimedia content saved on the NAS on a larger screen. You can also download and install versatile multimedia apps from Ubuntu Software Center via QNAP Linux Station. QNAP HD Station also allows users to directly enjoy the multimedia using the HD Player or third-party players such as Plex Home Theater.

Real-time transcoding for excellent multimedia experience on multiple devices


Equipped with the advanced Intel UHD 610 graphics card, the TVS-472XT supports 4K H.264 triple channel hardware decoding and real-time transcoding, allowing you to convert videos into universal file formats that can be played back smoothly on multiple devices.


Full backup scheduling


QNAP offers reliable and flexible backup and disaster recovery solutions to help businesses and organizations perform daily data backup tasks for computers, VM and other devices in a highly efficient manner.


Enhanced collaboration with easy file sharing and synchronisation


The TVS-472XT centrally stores data and files, and supports SMB/CIFS, AFP, and NFS protocols for file sharing over Windows, Mac, and Linux/UNIX networks. Combined with Qsync (a utility that turns a QNAP NAS into a secure, high-capacity data centre for file synchronisation), any file uploaded to the TVS-472XT will be made available to all related devices, such as desktops, laptops, and mobile devices. You can synchronise shared folders and team folders for group file sharing to improve the flexibility of team projects and collaborative work. Files can be managed centrally using File Station, including files from mobile devices and optical disk drives. In addition, File Station allows you to mount a remote NAS, and transfer files between your NAS and public cloud services for added convenience.


All-in-One Server to Host Virtual Machines and Containers


Virtualization Station allows you to host virtual machines (VMs) on the TVS-472XT and access them via web browser or VNC. Virtualization Station supports multiple operating systems, fast VM creation, VM backup/restore, VM import/export, snapshots and Device Management. This allows you to centrally manage your VMs. Virtualization Station also allows the TVS-472XT, VMs and containers to share the same network port. No more performance constraints on physical networks. High-speed virtual switches significantly speed up data transfer between VMs, containers, and the NAS through the internal interface. The TVS-472XT also features Container Station, which integrates LXC and Docker lightweight virtualization technologies. You can run multiple isolated Linux systems on the TVS-472XT and also download applications via the built-in Docker Hub Registry. Container Station also supports the QIoT Containers platform, which will help you quickly structure your IoT environment and deploy to your private IoT cloud.


More productivity applications


The application-based QTS operating system provides solutions to simplify file backup, management, search, and more. With File Station, you can view and manage your files not only from the NAS but also from different storage devices;OCR Converter allows you to extract text from images; Qfiling helps automate file organization; and Qsirch allows you to quickly find files.


Key Features :

  • Intel Pentium Gold G5400T 3.1 GHz dual-core
  • TVS-472XT-PT-4G: 4GB DDR4 (2 x 2GB) / 32 GB max
  • 4 x 3.5"/2.5" SATA 6Gb/s HDDs/SSDs
  • 2 x M.2 SSD Slot 2280/2260 PCIe 3.0 x2
  • HotSwapfunction
  • 1 x 120mm silent fan
  • 1 x 10GBASE-T and 2 x Gigabit Ethernet
  • 2 Thunderbolt ports and 4 USB 3.1 ports (2 Type C)
  • Antivirus, mail server, FTP, backup station, cloning, file sharing, download station, ...
  • Product compatibility list
Specifications
Select your criteria

General information

Product name

QNAP TVS-472XT-PT-4G

Brand

QNAP

Model

TVS-472XT-PT-4G

Processor

CPU frequency

3.1 GHz

Memory size

4 GB

Memory type

DDR4

Network

Network standard(s)

10 Gbps Gigabit Ethernet (10 GbE)
10/100/1000 Mbps

Network connector(s)

1 X 10 Gigabit Ethernet - RJ45 Female
2 X Gigabit Ethernet - RJ45 Female

Wake On LAN

Yes

DLNA certification

Yes

Storage

Capacity

0 GB

Internal interface

4 X Serial ATA 6Gb/s (SATA Revision 3)
2 X M.2 - PCI-E 3.0 x2

Hard drive format

2" 1/2
3" 1/2

Hard drive

Without hard drive

Number of discs

0

Max number of discs

4

RAID supported

Yes

Supported RAID Modes

10+spare
6+spare
6
5+spare
10
5
JBOD
1
0

File system

Ext4

Connector(s)

1 X HDMI Female
2 X USB 3.1 Type C Female
2 X USB 3.1
1 X USB 3.0
1 X PCI Express 3.0 x4
1 X PCI Express 3.0 x16
1 X Line OUT (3.5mm Jack Female)
1 X Line IN (3.5mm Jack Female)

Compatibility

Server functions

FTP
Printing
Web
iTunes
Video surveillance
Multimedia

Windows ADS

Yes

iSCSI (SCSI encapsulation)

Yes

Download without PC

Yes

Scalable

Yes

Supported OS

Microsoft Windows 8
Microsoft Windows 7
Microsoft Windows 10
Windows Server 2016
Windows Server 2012 R2
Windows Server 2012
Windows Server 2008 R2
Windows Server 2008
Windows 2003 Server
Linux
Mac OS X 10.7 or higher

Physical characteristics

Rackable

No

Sound level

28.1 dB

Consumption

37.32 W

Width

199.3 mm

Height

188.2 mm

Depth

279.6 mm

Weight

5.4 kg

Warranties

Commercial warranty

Seller 2 years

Legal warranty

See terms & conditions

Product referenced on 7 Dec 2018

Customer reviews
Global rating
5/10
based on 3 reviews Editorial and moderation guide
  • 33%
    1 review
  • 0%
  • 0%
  • 33%
    1 review
  • 33%
    1 review
  • by Anonymous
    Posted on 20 Aug 2021
    Bought on 24 Apr 2019 from LDLC
    Number of reviews: 1 Average rating: 2

    Too quickly disappointed

    Bought in April 2019, I find it too early, much too early considering the price of the equipment for the Nas to stop starting. Today, after a few attempts to start it up, it won't turn on at all. The 4 disks have been removed as well as the original ram cards. The only thing left is the red LED on the motherboard that lights up when the power supply is connected to the mains. Faulty power supply?
    The price did not reflect the "longevity" of the equipment.

    Review automatically translated
  • by GeorgesH
    Posted on 27 Sep 2019
    Bought on 26 Jul 2019 from LDLC
    Number of reviews: 2 Average rating: 10

    Works perfectly

    This nas works perfectly and is as expected.
    The Thunderbolt connection in addition to the Ethernet is a big plus in terms of speed on my workstation.

    Review automatically translated
  • by Toff
    Posted on 13 Jul 2019
    Bought on 7 Jun 2019 from LDLC
    Number of reviews: 3 Average rating: 7

    Unstable product

    I took this model for its thunderbolt connection
    I have been using it for about a month now
    I've been using it for about a month now, and it's been a great help to me.
    I've been using it for about a month now and it's not working properly.
    I'm not sure if it's a good idea for me to get a copy of the file that I'm using.
    I checked the disks in another send and there is no problem
    I'm not sure if I'm going to be able to use this product again, but I'm sure I'll be able to use it again.
    The product is really unstable and given the price I would have expected better
    So very disappointed by this purchase

    Review automatically translated
    Answer by [QNAP]: on 27 Nov 2019

    Hello TOFF, We are sorry that the product did not give you full satisfaction. We can try to solve this problem together. I invite you to make a ticket at the following link: service.qnap.com and to send us your ticket number at frsales@qnap.com. We will take care of your problem as soon as we receive your ticket. See you soon, The QNAP France team The QNAP France team
