Well-built case
The NZXT H7 is of good quality and very easy to use. Once fitted, the components are well ventilated. Everything looks great!
Review automatically translated
NZXT H7 Flow Black (2024).
Mid-tower case with tempered glass side window .
Pictures may differ from actual products
The NZXT H7 Flow mid-tower case introduces a new concept in graphics card cooling. The vertical layout of the power supply means that up to 3 x 120 mm fans can be installed at the bottom of the case for efficient cooling.
Mid-tower case with tempered glass side window .
LED RGB:
Case color:
LED RGB:
-
Yes
174€95In stock -
No
149€95In stock
Available from 142€45 on the outlet deals
Overview
NZXT H7 Flow: Improved GPU cooling
The NZXT H7 Flow mid-tower case introduces a new concept in graphics card cooling. The vertical layout of the power supply unit means that up to 3 x 120 mm fans can be fitted at the bottom of the case (not supplied) for efficient cooling without increasing the size of the case. On the component side, the H7 Flow will accommodate a Mini-ITX, Micro ATX, ATX or E-ATX motherboard (up to 272 mm) with a 410 mm graphics card. Finally, when it comes to mounting, it features an intuitive cable management system with wide channels, hooks and straps.
Key features
- Supports three bottom-mounted 120 mm fans for the GPU.
- Equipped with three front-mounted F120Q Airflow fans for efficient cooling right out of the box.
- Mesh panels maximise airflow for intake and exhaust, as well as dust filtration.
- Supports radiators up to 420 mm at the front and 360 mm at the top.
- Intuitive cable management system with wide channels, integrated hooks and included straps for easy routing.
- Capacity for up to 10 120 mm fans: 3 top, 3 front, 3 bottom and 1 rear.
- 2 x USB 3.0 + 1 x USB 3.1 Type C located on the top panel.
- Tool-free access to front, top and side panels for easy construction and levelling.
Specifications
Select your criteria
General information |
Product name |
NZXT H7 Flow Black (2024). |
Brand |
NZXT | |
Model |
CM-H72FB-01 | |
Main characteristics |
Graphic card max. length |
410 mm |
Max height CPU fan |
185 mm | |
Power supply max. length |
200 mm | |
Power format |
ATX/EPS | |
Case format |
Mid tower | |
Use |
Office | |
| Gamer | ||
Material |
Tempered glass | |
| Steel | ||
Motherboard format |
ATX | |
| E-ATX | ||
| Micro ATX | ||
| Mini ITX | ||
Power supply supplied |
No | |
Design |
Screwless fixing system |
Yes |
Case color |
Black | |
Front color |
Black | |
Integrated display |
No | |
Mesh front |
Yes | |
Glass |
Yes | |
Tempered glass |
Yes | |
Fish tank (panoramic view) |
No | |
LED RGB |
No | |
ARGB LED |
No | |
Water cooling compatible |
Yes | |
Motherboard connector location |
Standard connectors (on the motherboard) | |
Expansion slots |
Number of PCI slots |
7 |
Low profile |
No | |
Number of 2.5" slots |
2 | |
Number of 2.5"/3.5" slots |
2 | |
Front connectivity |
Location of expansion ports |
Top |
Connector(s) available |
1 X 3.5mm Jack Female Stereo | |
| 2 X USB 3.0 | ||
| 1 X USB 3.1 Type C | ||
Cooling |
Fan(s) included |
Yes |
Number of rear fan(s) slots |
1 X 120 or 140mm | |
Quantity of rear fan(s) supplied |
0 | |
Number of front fan(s) slots |
3 X 120 or 140mm | |
Quantity of front fan(s) supplied |
3 | |
Number of above fan(s) slots |
2 X 120 or 140mm | |
| 1 X 120mm | ||
Quantity of above fan(s) supplied |
0 | |
Number of underneath fan(s) slots |
3 X 120mm | |
Quantity of underneath fan(s) supplied |
0 | |
Water cooling |
AIO radiator compatibility |
420mm radiator |
| 360mm radiator | ||
| 280mm radiator | ||
| 240mm radiator | ||
Front AIO slot(s) |
240mm radiator | |
| 280mm radiator | ||
| 360mm radiator | ||
| 420mm radiator | ||
Above AIO slot(s) |
360mm radiator | |
| 280mm radiator | ||
| 240mm radiator | ||
Rear AIO slot(s) |
N/A | |
Physical characteristics |
Width |
244 mm |
Height |
544 mm | |
Depth |
468 mm | |
Weight |
11.13 kg | |
Volume |
60.7 l | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
See all NZXT products
Product referenced on 28 Jun 2024
