ASUSTOR Lockerstor 4 Gen 3 AS6806T.
Barebone 6-bay NAS server 16GB DDR5 AMD Ryzen V3C14 - 2x 10 GbE + 2x 5 GbE.
Pictures may differ from actual products
The AS6806T Lockerstor 4 Gen 3 from ASUSTOR is a 6-bay 2.5"/3.5" SATA NAS network storage server with four M.2 2280 PCIe 4.0 slots. Powered by a AMD Ryzen V3C14 Quad-Core processor and 16GB of DDR5 ECC RAM, it will be at home in any business environment.
Barebone 6-bay NAS server 16GB DDR5 AMD Ryzen V3C14 - 2x 10 GbE + 2x 5 GbE.
Performance and reliability for professionals
The AS6806T Lockerstor 4 Gen 3 from ASUSTOR is a 6-bay 2.5"/3.5" SATA NAS network storage server with four M.2 2280 PCIe 4.0 slots for caching and/or SSD storage. Powered by a AMD Ryzen V3C14 Quad-Core processor and 16GB of DDR5 ECC RAM, it will be at home in any business environment. Featuring a rich network connectivity with 2 x 10 Gigabit Ethernet ports and 2 x 5 Gigabit Ethernet ports, it will avoid latency on your professional network infrastructure.
Performance to match
The Ryzen Embedded SoCs fromAMD are so efficient that they deliver both energy savings and uncompromising desktop-class performance. Four cores up to 3.8 GHz help you transfer, store, create and much more with great efficiency.
ECC memory is commonly used in servers to detect and correct the most common types of data corruption, which can help to prevent data loss due to electromagnetic interference or crashes, giving this NAS server great stability.
Excellent storage potential
The ASUSTOR Lockerstor 4 Gen 3 NAS server is particularly fast. The combination of the integrated Ryzen SoC fromAMD, M.2 SSDs using PCIe 4.0, USB4 and dual 10GbE ensures that everything you want to do with your NAS will be done extremely quickly. The M.2 slots now support PCI Express 4.0, which doubles performance compared to PCI Express 3.0. With four M.2 slots for NVMe SSDs and 4 bays for hard drives (or more with an expansion unit, not supplied), the Lockerstor Gen3 series guarantees you the best in terms of speed and storage capacity.
High-performance connectivity
The Lockerstor Gen3 series is equipped with two high-speed USB4 ports, offering ultra-fast speeds of up to 40 Gbps. The USB4 ports are compatible with Thunderbolt 3/4 devices, allowing you to transfer, store, archive and backup faster than ever before. By connecting two ASUSTOR NAS units using the USB4 ports, fast data transfer, synchronization and backup is possible without using network ports. Combined with features such as DataSync Center and SMB Backup, this can dramatically reduce backup time.
Efficient cooling
With all these features packed into a small footprint, the Lockerstor Gen3 series and the AMD Ryzen Embedded SoCs installed require the best cooling solution. The Lockerstor Gen3 heat dissipation solution uses heat pipes and fins to dissipate waste heat from the processor, allowing the Lockerstor Gen3 to perform virtually any storage task you throw at it.
Key features :
- Integrated processor AMD Ryzen quad-core V3C14 (Quad Core 2.3 GHz - 3.8 GHz in Turbo mode)
- ECC RAM -16 GB ECC DDR5-4800 (Max 64GB)
- Four M.2 slots for NVMe SSDs - Double the performance with PCIe 4.0
- 2 x 40 Gbit/s USB4 ports
- 3 USB 3.2 Gen 2 Type-A ports at 10 Gbit/s
- 2 ports 10 Gigabit Ethernet + 2 ports 5-Gigabit Ethernet
- Supports Wake on LAN and Wake on WAN (5 GbE)
Select your criteria
General information |
Product name |
ASUSTOR Lockerstor 4 Gen 3 AS6806T. |
Brand |
ASUSTOR | |
Model |
AS6806T | |
Processor |
CPU frequency |
3.8 GHz |
Memory size |
16 GB | |
Memory type |
DDR5 ECC | |
Network |
Network standard(s) |
10 Gbps Gigabit Ethernet (10 GbE) |
| 5 Gbps Gigabit Ethernet (5 GbE) | ||
Network connector(s) |
2 X 10 Gigabit Ethernet - RJ45 Female | |
| 2 X 5 Gigabit Ethernet - RJ45 Female | ||
Wake On LAN |
Yes | |
DLNA certification |
Yes | |
Storage |
Capacity |
0 GB |
Internal interface |
6 X Serial ATA 6Gb/s (SATA Revision 3) | |
| 4 X M.2 - PCI-E 4.0 x4 | ||
Hard drive format |
2" 1/2 | |
| 3" 1/2 | ||
| M.2 | ||
Hard drive |
Without hard drive | |
Number of discs |
0 | |
Max number of discs |
6 | |
RAID supported |
Yes | |
Supported RAID Modes |
0 | |
| 1 | ||
| 10 | ||
| 5 | ||
| 6 | ||
| JBOD | ||
| Single Disk | ||
File system |
Ext4 | |
| Btrfs | ||
Connector(s) |
2 X USB4 (Type-C) | |
| 3 X USB 3.1 | ||
Compatibility |
Server functions |
FTP |
| Printing | ||
| Multimedia | ||
| Photo | ||
| Video surveillance | ||
| Virtualization | ||
| Web | ||
Windows ADS |
Yes | |
iSCSI (SCSI encapsulation) |
Yes | |
Download without PC |
Yes | |
Scalable |
Yes | |
Supported OS |
Microsoft Windows 11 | |
| Microsoft Windows 10 | ||
| Windows Server 2022 | ||
| Windows Server 2019 | ||
| Windows Server 2016 | ||
Physical characteristics |
Rackable |
No |
Sound level |
18.1 dB | |
Consumption |
45 W | |
Width |
233 mm | |
Height |
185.5 mm | |
Depth |
230 mm | |
Weight |
3.2 kg | |
Warranties |
Commercial warranty |
Seller 3 years
|
Legal warranty |
See terms & conditions
|
|
Safety Information |
Responsible person |
Asustor B.V. |
Postal address |
Hoofdweg-Zuid 16, 2912 ED Nieuwerkerk ad IJssel, The Netherlands | |
Electronic Address |
contact@asustor.com |
