Corsair 6500X (White/Aluminium).
Medium Tower case with tempered glass panel and front - Compatible with ASUS BTF and MSI Project Zero.
Pictures may differ from actual products
The Corsair 6500X dual-compartment mid-tower case offers an unobstructed and organised view of your configuration through its two tempered glass sides. It can accommodate up to 10 x 120 mm fans or 7 x 140 mm fans and comes with several mounting options for AiO.
Medium Tower case with tempered glass panel and front - Compatible with ASUS BTF and MSI Project Zero.
Two-compartment mid-tower PC case
The Corsair 6500X dual-compartment mid-tower case offers an unobstructed and organised view of your configuration through its two tempered glass sides. It can accommodate up to 10 x 120mm fans or 7 x 140mm fans and with a range of top, bottom and side heatsink mounting options, your system will deliver excellent performance. Compatibility with rear connector motherboards gives you a cable-free view of your system.
Major advantages
- The design of the 6500X allows you to show off your setup behind tempered glass panels on the front and side.
- Dual compartment design for efficient cooling and a more streamlined, organised system. One compartment with multiple fan and radiator mounts, and a second compartment for cable routing, storage and PSU.
- Compatible with motherboards with rear connectors: Can be used with ASUS BTF and MSI Project Zero motherboards so no cables spoil the view.
- Optimise your cooling system with enough space for up to 10 x 120 mm fans or 7 x 140 mm fans and several slots for mounting a 360 mm radiator top, bottom or sideways.
- Storing cables in the second compartment makes it easier to create a PC with a clean, uncluttered look.
- Tool-free disk holders for up to two 2.5"/3.5" hard disks
- Easily access your peripherals with USB-C 3.1, two USB 3.0 ports and a 3.5 mm combo audio jack.
- Supports iCUE LINK systems with built-in iCUE LINK cable hooks to build your dream system even more easily.
Select your criteria
General information |
Product name |
Corsair 6500X (White/Aluminium). |
Brand |
Corsair | |
Model |
CC-9011285-WW | |
Main characteristics |
Graphic card max. length |
400 mm |
Max height CPU fan |
190 mm | |
Power supply max. length |
225 mm | |
Power format |
ATX/EPS | |
Case format |
Mid tower | |
Use |
Gamer | |
| Office | ||
Material |
Steel | |
| Tempered glass | ||
| Aluminum | ||
Motherboard format |
Micro ATX | |
| Mini ITX | ||
| ATX | ||
| E-ATX | ||
Power supply supplied |
No | |
Design |
Screwless fixing system |
Yes |
Case color |
White | |
Front color |
Gray | |
Dust filters |
3 | |
Integrated display |
No | |
Mesh front |
No | |
Glass |
Yes | |
Tempered glass |
Yes | |
Fish tank (panoramic view) |
Yes | |
LED RGB |
No | |
ARGB LED |
No | |
Water cooling compatible |
Yes | |
Motherboard connector location |
Connectors under the motherboard | |
| Standard connectors (on the motherboard) | ||
Expansion slots |
Number of PCI slots |
8 |
Low profile |
No | |
Number of 2.5"/3.5" slots |
2 | |
Front connectivity |
Location of expansion ports |
Top |
Connector(s) available |
1 X 3.5mm Jack Female Stereo | |
| 4 X USB 3.0 | ||
| 1 X USB 3.1 Type C | ||
Cooling |
Fan(s) included |
No |
Number of rear fan(s) slots |
1 X 120 or 140mm | |
Quantity of rear fan(s) supplied |
0 | |
Quantity of front fan(s) supplied |
0 | |
Number of side fan(s) slots |
3 X 120mm | |
Quantity of side fan(s) supplied |
0 | |
Number of above fan(s) slots |
3 X 120 or 140mm | |
Quantity of above fan(s) supplied |
0 | |
Number of underneath fan(s) slots |
3 X 120 or 140mm | |
Quantity of underneath fan(s) supplied |
0 | |
Water cooling |
AIO radiator compatibility |
120mm radiator |
| 280mm radiator | ||
| 360mm radiator | ||
| 240mm radiator | ||
| 140mm radiator | ||
Front AIO slot(s) |
N/A | |
Above AIO slot(s) |
280mm radiator | |
| 240mm radiator | ||
| 360mm radiator | ||
Rear AIO slot(s) |
120mm radiator | |
| 140mm radiator | ||
Physical characteristics |
Width |
328 mm |
Height |
496 mm | |
Depth |
481 mm | |
Weight |
14 kg | |
Volume |
62.5 l | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
See all Corsair products
Product referenced on 12 Jul 2024
For the moment, there are no customer reviews.Write a review
