QNAP QSW-M2106-4S
6-port 2.5 GbE manageable web switch + 4 SFP+ 10 Gbps slots
Pictures may differ from actual products
The QNAP QSW-M2106-4S is a manageable Layer 2 web switch that offers 6 x 2.5 Gigabit LAN ports and 4 x 10 Gbps SFP+ slots. The QSW-M2106-4S is configured via the easy-to-use QNAP Web Swith System (QSS) interface.
6-port 2.5 GbE manageable web switch + 4 SFP+ 10 Gbps slots
Manageable Layer 2 Web Switch with 2.5 GbE and 10 GbE Connectivity
The QNAP Switch QSW-M2106-4S is a manageable Layer 2 web switch that offers 6 x 2.5 Gigabit LAN ports and 4 x 10 Gbps SFP+ slots. The QSW-M2106-4S is configured via the easy-to-use QNAP Web Swith System (QSS) interface.
With its compact and modern design, the QSW-M2106-4S fits perfectly with other devices in the modern digital office. The flexible DC power connector also allows the QSW-M2106-4S to be universally deployed. Being fully plug-and-play, you simply connect the QSW-M2106-4S to your devices and it will do the rest.
Flexible deployment
The QSW-M2106-4S provides four 10 Gbps SFP+ ports and six 2.5 Gigabit ports to connect different devices and establish high-speed hybrid networks. With SFP+ interfaces, it is possible to use DAC (direct attach copper) cables to connect directly to SFP+ devices. Alternatively, you can use 10G-SFP-T copper transceiver modules to connect 10GBASE-T/NBASE-T devices via Category 6, 5 or 5e RJ45 cabling. The switching capacity of the QSW-M2106-4S is 110 Gbps, which guarantees the full potential of each port.QSS Dashboard
The QSW-M2106-4S uses the QNAP Switch System (QSS) with an easy-to-use web-based graphical user interface (GUI) full of value-added features to simplify network configuration and management.
The QSW-M2106-4S provides bandwidth and packet control functions (including LACP, VLAN, QoS and IGMP Snooping) to boost network performance through IP bundling and bandwidth management. It also has powerful system and security features (including ACL, LLDP, RSTP, and Flow Control) to help administrators improve network reliability at the network level.It also has powerful system and security features (including ACL, LLDP, RSTP and Flow Control) to help administrators improve network reliability through access controls, troubleshooting, loop prevention and packet loss avoidance.
Select your criteria
General information |
Product name |
QNAP QSW-M2106-4S |
Brand |
QNAP | |
Model |
QSW-M2106-4S | |
Technical specifications |
Number of ports |
10 |
Network standard(s) |
10 Gbps Gigabit Ethernet (10 GbE) | |
| 2.5 Gbps Gigabit Ethernet (2.5 GbE) | ||
Number of GBIC ports |
4 | |
Rackable |
No | |
Manageable |
Yes | |
Administration level |
Level 2 | |
SNMP |
No | |
PoE (Power over Ethernet) |
No | |
Width |
290 mm | |
Depth |
127 mm | |
Height |
42.5 mm | |
Weight |
1.15 kg | |
Consumption |
36 W | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
