Synology WRX560

AX3000 Wireless 6 Router (2400 Mbps + 600 Mbps) 3 Gigabit LAN ports, 1 2.5 GbE LAN/WAN port and 1 10/100/1000 Mbps WAN port

Pictures may differ from actual products

Synology's WRX560 is a high-performance, feature-rich router designed for busy homes and home offices. Take advantage of the Mesh network capacity for uninterrupted coverage throughout your home.

AX3000 Wireless 6 Router (2400 Mbps + 600 Mbps) 3 Gigabit LAN ports, 1 2.5 GbE LAN/WAN port and 1 10/100/1000 Mbps WAN port

Overview

Feature-rich Wi-Fi 6 Wireless Router

Synology's WRX560 is a high-performance, feature-rich router designed for busy homes and home offices. Take advantage of the Mesh network capacity for uninterrupted coverage throughout the house. Support for 3 Gbps wireless speeds and up to 150 connected devices ensures fast, uninterrupted Internet connectivity, even in busy network environments. Powered by the ever-evolving Synology Router Manager operating system, the WRX560 is designed to simplify the protection and management of your network.

Highlights

  • Dual Band Wi-Fi 6 with 5.9GHz support and configurable 2.5GbE WAN/LAN port for fast wireless and wired transfers.
  • Advanced network security: Comprehensive network security available with Threat Prevention, VLAN segmentation and WPA3 support.
  • Mesh-compatible: Standalone router can be integrated into a mesh system for whole-house coverage.
  • Secure Internet access for families: Parental controls and web filtering protect your family.
  • Easy setup and management: The DS router app makes it easy to set up and manage the network via your mobile device.
  • Easy Remote Access : This complete VPN server solution, with remote desktop and site-to-site tunneling, allows for flexible and secure remote connection.

Full Parental Control by Synology Router Manager

  • Profiles for Easy Management: Create profiles for family members and assign them devices to easily manage Internet access and monitor devices connected to your local network.
  • Understand usage: Get information about your children's online activities, such as how much time they spend on the web on a daily basis or whether they have attempted to visit inappropriate websites.
  • Limit children's screen time: Set Internet usage quotas or limit Internet access to certain times for each of your children's devices. Set the amount of time you can spend on laptops, smartphones and games consoles.
  • Web filtering: Prevent children from accessing adult, violent, gaming and social networking websites and explicit search results. Apply filters flexibly, for example by restricting access to social networks during working hours.

Designed for busy network environments

The WRX560 is designed to provide fast and reliable performance for wired and wireless devices in harsh network environments.

  • Quad-Dore 1.4 GHz processor and 512 MB DDR4 memory provide fast and stable operation for up to
    150 connected devices, even when advanced features are enabled.
  • Dual-Band Wi-Fi (2.4GHz & 5GHz), in conjunction with Smart Connect, optimises wireless connection speed by intelligently redirecting your device to the optimum Wi-Fi band, depending on your location.
  • Enhanced 5.9GHz band support provides access to an interference-free band, allowing for potentially higher connection speeds or a dedicated wireless link.
  • Flexible 2.5 GbE port can be configured for use over a WAN or LAN to take full advantage of ISP broadband packages, or to connect locally to workstations or high-speed NAS.
  • Mesh features allow you to create a complete home wireless Mesh network with a unique network name using multiple Synology routers.

Go Mobile

  • Easy Setup: Install the app and simply follow the on-screen instructions to perform setup directly from your smartphone without using a computer.
  • Remote Parental Controls: Access Parental Controls from your phone to create profiles, monitor usage, block internet access, and approve access requests to specific pages.
  • Traffic Monitoring: Find out if users are overloading the network or visiting inappropriate sites and restrict access if necessary.
  • Manage from anywhere: Perform router management tasks such as configuring the Wi-Fi network and changing passwords even when you're on the move.
Specifications
Select your criteria

General information

Product name

Synology WRX560

Brand

Synology

Model

WRX560

Router

Modem/Router type

WIFI Router

Network standard(s)

10/100/1000 Mbps
2.5 Gbps Gigabit Ethernet (2.5 GbE)
Wi-Fi 6 AX
Wi-Fi AC
Wi-Fi N (IEEE 802.11n)
Wi-Fi 6 AX 3000 (IEEE 802.11ax)
Wi-Fi A (IEEE 802.11a)

Wireless

Yes

Mesh Wi-Fi (mesh/multiroom network)

Yes

Dual-Band

Yes

IPv6 compatible

Yes

Network connector(s)

3 X LAN or DMZ - Gigabit - RJ45
1 X WAN - Gigabit Ethernet - RJ45
1 X WAN or LAN - 2.5 GbE - RJ45

Modem

Integrated Modem

No

Interface with the computer

2.5 Gigabit Ethernet - RJ45 Female
Gigabit Ethernet - RJ45 Female
Wi-Fi
USB 3.0

Physical characteristics

Width

233 mm

Height

194 mm

Depth

66 mm

Weight

1.35 kg

Power supply

Consumption

10.8 W

Standby consumption

7.94 W

Warranties

Commercial warranty

Seller 3 years

Legal warranty

See terms & conditions

Product referenced on 22 Dec 2022

Customer reviews
Global rating
10/10
based on 2 reviews Editorial and moderation guide
  • 100%
    2 reviews
  • 0%
  • 0%
  • 0%
  • 0%
  • by Matthieu B.
    Posted on 11 Jun 2023
    Bought on 7 May 2023 from LDLC
    Number of reviews: 5 Average rating: 10

    All Synology's experience and quality at your Internet's service

    This router incorporates all of Synology's experience, this time at the service of networks.
    The router is extremely comprehensive (in addition to the basic functions, it offers dual WAN, Wifi 6, the ability to create multiple local networks & Wifi networks, parental control, VPN server, download utility, etc.) and the interface is simple and user-friendly to manage.
    The network performance is excellent, whether wired (Ethernet) or wireless.
    An excellent router that I can't recommend highly enough.

    Review automatically translated
  • by Joel L
    Posted on 10 Apr 2023
    Bought on 9 Mar 2023 from LDLC
    Number of reviews: 2 Average rating: 10

    Perfect

    Always perfect service and I received the device on time. The purchase corresponds well to my expectations.

    Review automatically translated

In the same universe: synology routeur
