StarTech.com PCI Express to 2 Port USB 3.1 Type-A Controller Card with UASP
PCI-Express 1x controller card with 2 USB 3.1 type-A ports
Pictures may differ from actual products
This PCIe USB 3.1 controller card designed by StarTech.com fits into a free PCI-Express x4 slot on your computer and allows you to upgrade your current system by adding two SuperSpeed USB-A (10 Gb/s) ports.
PCI-Express 1x controller card with 2 USB 3.1 type-A ports
Overview
Add 2 USB 3.1 Type A (10 Gb/s) ports for your PCI Express compatible PC
This USB 3.1 PCIe controller carddesigned by StarTech.com fits into a free PCI-Express x4 slot on your computer and allows you to upgrade your current system by adding two SuperSpeed USB-A (10 Gb/s) ports. This controller card allows you to connect two USB-A Gen 2 (10 Gb/s) devices to your desktop computer. The USB-A ports are ideal for connecting USB devices such as external hard drives and SSDs, or for powering and synchronizing your mobile devices. USB-A ports provide up to 4.5W (5V/0.9A) of power per USB port and are backwards compatible with USB 3.2 Gen 1 (5Gb/s) and USB 2.0 (480Mb/s) devices.
The USB 3.2 Gen 2 card features an ASMedia ASM3142 host controller that uses two lanes of the PCIe 3.0 bus, enabling it to achieve 10 Gb/s throughput on each port and provide fast access to high-performance devices such as NVMe and SSD drives. The controller card supports "Multiple Ins" to maintain maximum speed when multiple devices are connected, even via a USB hub (note: the USB hub must also support this feature). It also supports the UASP protocol to improve the performance of storage devices.
The expansion card comes with full-height and half-height installation brackets to allow you to install it in a matching PCIe 3.0 x4 slot (backwards compatible with PCIe 2.0). It is compatible with Windows, Linux and macOS, so it supports many platforms. Drivers install automatically on computers running Windows 8 or later for easy installation. Compatible with USB 3.1/3.0/2.0 devices
Features:
- Adds 2 external USB 3.1 ports with UASP support
- Supports transfer speeds up to 10 Gb/s
- Complies with PCI Express 3.0 x4specifications
- 2-port USB PCIe card with ASMedia ASM3142 controller (PCIe 3.0 x4), 2x SuperSpeed USB-A 10 Gb/s (USB 3.1 Gen 2 / USB 3.2 Gen 2x1); max. 10 Gb/s throughput per port
- Expansion card supports Multiple INs, to maintain maximum speed with mixed speed devices, and UASP
- Optimised for SSD/HDD, NVMe and USB drives; compatible with USB 3.0/2.0
- Power: USB 3.0 PCI Express expansion card with SATA power socket provides up to 4.5W (5V @ 0.9A) of additional power to USB ports per USB-A port
- Compatibility: USB PCIe card installs in a full/half height PCIe 3.0 x4 slot
- Mounting bracket included
- Backward compatible with PCIe 2.0
- Supports Win/Linux/macOS with automatic drivers on Windows 8 and later
Specifications
Select your criteria
General information |
Product name |
StarTech.com PCI Express to 2 Port USB 3.1 Type-A Controller Card with UASP |
Brand |
StarTech.com | |
Model |
PEXUSB312A3 | |
Technical specifications |
Bus |
PCI Express 3.0 x4 |
Controllers |
USB 3.1 | |
Connector(s) |
2 X USB 3.1 | |
Supported OS |
Linux 2.6 | |
| Windows 2003 Server | ||
| Windows Server 2008 R2 | ||
| Windows Vista | ||
| Microsoft Windows 10 | ||
| Microsoft Windows 11 | ||
| Microsoft Windows 7 | ||
| Microsoft Windows 8 | ||
| Microsoft Windows 8.1 | ||
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
Product referenced on 7 Mar 2022
