Synology DiskStation DS3617xsII
12-bay NAS server - 16 GB DDR4 ECC SO-DIMM RAM - Intel Xeon D-1527
Last price 2 519€95
High Performance NAS Server with Flexibility and Scalability
Synology DiskStation DS3617xsII is a 12-bay desktop NAS that enables instant deployment with scalability up to 36 bays with 2 expansion units, providing an outstanding sequential read throughput of 2359 MB/s. The DS3617xsII is certified for VMware, Citrix, Hyper-V and OpenStack, designed to bring superior flexibility and efficiency to businesses. It is equipped with an Intel Xeon D-1527 processor with 16GB of DDR4 RAM and 4 x 1GbE LAN ports.
High Performance NAS
Equipped with an Intel Xeon D-1527 quad-core (8-threaded) processor, the DS3617xsII delivers an astounding performance of over 2359 Mp/s sequential throughput in RAID 5 configuration with 10 GbE and Link Aggregation enabled. Initially equipped with 16GB of DDR4 ECC RAM (expandable to 48GB), it ensures data accuracy when processing high-value data and critical tasks in large enterprises.
expandability
The PCIe 3.0 slot allows for faster networking as you expand your infrastructure. With four integrated Gigabit ports, the DS3617xsII provides comprehensive connectivity options for link aggregation and swap configurations.
Collaborate on Your Private Cloud
Synology Office is a collaborative package that combines the convenience and ease of use of public clouds with the data privacy and security of private clouds. It allows you to work seamlessly on documents and spreadsheets in a protected environment.
- Real-time collaboration on the same documents online to increase productivity,
- Instant communication on Synology Chat while editing documents or spreadsheets
- Version control allows you to browse through all changes and retrieve previous versions with a single click
Ready for Virutalisation
The DS3617xsII offers storage solutions perfect for virtualisation environments including VMware, Citrix, Hyper-V and OpenStack. With certified integration with VMware vSphere 6 and VAAI, the DS3617xsII helps offload specific storage operations and optimizes compute power for unmatched performance and efficiency in VMware environments.
As the centralized storage of a virtual environment, the DS3617xsII enables virtual machine migration, facilitating server-to-server movement, while eliminating service interruptions and disruptions to users. Support for Windows Offloaded Data Transfer (ODX) and Synology Advanced LUN greatly improves efficiency during massive data transfers and migrations.
With OpenStack support, you can use the DS3617xsII as a block storage component for Cinder API-enabled servers.
Key Features :
- Intel Xeon D-1527 processor (Quad-Core 2.2 GHz / 2.7 GHz Turbo - 8 Threads - 6 MB Cache)
- 12 SATA 6 Gbps 2.5"/3.5" bays expandable to 36 with two DX1215, DX1215II expansion units
- 16 GB DDR4 ECC SO-DIMM (expandable to 48 GB) compatible modules: D4ECSO-2666-16G, D4ECSO-2400-16G, RAMEC2133DDR4SO-16G
- PCIe 3.0 x8 slot compatible with E10G21-F2, E10G18-T2, E10G18-T1, E10G17-F2, E25G21-F2, M2D18
- VPN connection: 40 max.
- Support for 75 IP cameras(2 licenses included)
- Network protocols: SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP)
Select your criteria
General information |
Product name |
Synology DiskStation DS3617xsII |
Brand |
Synology | |
Model |
DS3617XSII | |
Processor |
CPU frequency |
2.2 GHz |
Memory size |
16 GB | |
Memory type |
DDR4 ECC | |
Network |
Network standard(s) |
10/100/1000 Mbps |
Network connector(s) |
4 X Gigabit Ethernet - RJ45 Female | |
Wake On LAN |
Yes | |
DLNA certification |
No | |
Storage |
Capacity |
0 GB |
Internal interface |
12 X Serial ATA 6Gb/s (SATA Revision 3) | |
Hard drive format |
2" 1/2 | |
| 3" 1/2 | ||
Hard drive |
Without hard drive | |
Number of discs |
0 | |
Max number of discs |
12 | |
RAID supported |
Yes | |
Supported RAID Modes |
0 | |
| 1 | ||
| 10 | ||
| 5 | ||
| 6 | ||
| F1 | ||
| JBOD | ||
File system |
Ext4 | |
| Btrfs | ||
Connector(s) |
1 X PCI Express 3.0 x4 | |
| 2 X USB 3.0 | ||
Compatibility |
Server functions |
Web |
| Virtualization | ||
| Video surveillance | ||
| Photo | ||
| Multimedia | ||
| FTP | ||
Windows ADS |
Yes | |
iSCSI (SCSI encapsulation) |
Yes | |
Download without PC |
Yes | |
Scalable |
Yes | |
Supported OS |
Microsoft Windows 8 | |
| Microsoft Windows 7 | ||
| Microsoft Windows 10 | ||
| Mac OS X 10.12 or higher | ||
Physical characteristics |
Rackable |
No |
Width |
300 mm | |
Height |
270 mm | |
Depth |
340 mm | |
Weight |
9.8 kg | |
Warranties |
Commercial warranty |
Seller 2 years |
Legal warranty |
See terms & conditions |
See all Synology products
Product referenced on 12 May 2021
For the moment, there are no customer reviews.Write a review
