Just like the other NZXT H-series cases, the H510 is designed for performance and silence. Elegantly designed with a tempered glass panel, it is ready for the configuration of your dreams. Fully compliant with the H series standards, it can accommodate a Mini-ITX, Micro ATX and ATX motherboard with a 381mm graphics card.
The NZXT H510 case is ideal for creating your own machine. Ready for Mini-ITX, Micro ATX and ATX motherboards, you can install a graphics card up to 381mm long. This high-end mid-tower case also features NZXT's famous patented cable management system, removable fan/heat sink mounting brackets and easy-to-use drive trays.
With its high quality steel construction, the H510 is a solid and stylish enclosure. To allow you to design a more efficient configuration, it offers 3 internal 2.5" bays and 3 internal 3.5" bays. It also includes 2 Aer F120mm fans to promote good ventilation. Its beautiful tempered glass panel enhances the aesthetics of your entire system. Finally, you can count on the USB 3.1 Gen 2 Type-C port and the USB 3.1 Gen 1 Type-A port, as well as the 7 PCI slots to take full advantage of your PC.
Select your criteria
General information |
Product name |
NZXT H510 White |
Brand |
NZXT | |
Model |
CA-H510B-W1 | |
Main characteristics |
Graphic card max. length |
381 mm |
Max height CPU fan |
165 mm | |
Power format |
ATX/EPS | |
Case format |
Mid tower | |
Use |
Gamer | |
| Office | ||
Material |
Plastic | |
| Tempered glass | ||
| Steel | ||
Motherboard format |
ATX | |
| Micro ATX | ||
| Mini ITX | ||
Power supply supplied |
No | |
Design |
Case color |
White |
Front color |
White | |
Dust filters |
2 | |
Glass |
Yes | |
Tempered glass |
Yes | |
LED RGB |
No | |
Water cooling compatible |
Yes | |
Expansion slots |
Number of PCI slots |
7 |
Low profile |
No | |
Number of visible 3.5" slots |
0 | |
Number of invisible 3.5" slots |
2 | |
Number of 2.5" slots |
2 | |
Number of 2.5"/3.5" slots |
1 | |
Number of visible 5.25" slots |
0 | |
Number of invisible 5.25" slots |
0 | |
Number of Slot-in slim 5.25'' slots |
0 | |
Number of Slim 5.25'' slots |
0 | |
Front connectivity |
Location of expansion ports |
Top |
Connector(s) available |
1 X Headphone (3.5mm Jack Female) | |
| 1 X Microphone (3.5mm Jack Female) | ||
| 1 X USB 3.0 | ||
| 1 X USB 3.1 Type C | ||
Cooling |
Number of rear fan(s) slots |
1 X 120mm |
Quantity of rear fan(s) supplied |
1 | |
Number of front fan(s) slots |
2 X 120 or 140mm | |
Quantity of front fan(s) supplied |
0 | |
Number of above fan(s) slots |
1 X 120 or 140mm | |
Quantity of above fan(s) supplied |
1 | |
Water cooling |
AIO radiator compatibility |
280mm radiator |
| 240mm radiator | ||
| 120mm radiator | ||
Front AIO slot(s) |
280mm radiator | |
| 240mm radiator | ||
Rear AIO slot(s) |
120mm radiator | |
Physical characteristics |
Width |
210 mm |
Height |
460 mm | |
Depth |
428 mm | |
Weight |
6.6 kg | |
Warranties |
Commercial warranty |
Seller 2 years |
Legal warranty |
See terms & conditions |
See all NZXT products
Product referenced on 16 Jun 2019
This case is really beautiful, the white colour makes it very "design" and elegant.
There is plenty of room for my RTX 2070 Super graphics card. The fans supplied with the case are efficient and rather quiet.
The presence of a USB Type C port on the upper front is a plus for me. Finally, the installation of the components is quite simple with this case and the cable management is quite intuitive.
I recommend it.
