Gigabyte GeForce RTX 4080 SUPER WINDFORCE OC V2 16G

16 GB GDDR6X - HDMI/Tri DisplayPort - DLSS 3 - PCI Express (NVIDIA GeForce RTX 4080 SUPER)

Pictures may differ from actual products

For ultra-realistic, ultra-fluid and ultra-immersive games, the Gigabyte GeForce RTX 4080 SUPER WINDFORCE OC V2 16G graphics card puts the most advanced technologies at your disposal to enable you to play in the best possible conditions, in very high resolution or in Virtual Reality.

16 GB GDDR6X - HDMI/Tri DisplayPort - DLSS 3 - PCI Express (NVIDIA GeForce RTX 4080 SUPER)

  • NVIDIA GeForce RTX
  • NVIDIA G-SYNC
Overview

Exceptional gaming performance

For ultra-realistic, ultra-fluid and ultra-immersive games, the Gigabyte GeForce RTX 4080 SUPER WINDFORCE OC V2 16G graphics card puts the most advanced technologies at your disposal to enable you to play in the best possible conditions, in very high resolution or in Virtual Reality. Designed for gamers and creators, the NVIDIA GeForce RTX 4080 SUPER graphics card features 10240 CUDA cores and a 256-bit memory interface. It delivers remarkable performance thanks to DLSS 3, hardware ray tracing andartificial intelligence.

Gigabyte GeForce RTX 4080 SUPER WINDFORCE OC V2 16G

Gigabyte offers a graphics card based on the NVIDIA Ada Lovelace architecture, offering a remarkable combination of performance and efficiency. This card features factory overclocking and an exclusive cooling system, equipped with three ultra-high-performance fans (WINDFORCE 3X, 3x 100 mm), an aluminium radiator and 7 copper heatpipes.

NVIDIA Ada Lovelace architecture

This new architecture will keep you one step ahead. It's ahead of its time and ahead of the game.

  • New streaming multiprocessors: up to 2 times more performance and energy efficiency
  • Fourth-generation Tensor cores: Up to 2x more AI performance
  • Third-generation RT cores: Up to 2x more ray tracing performance and realistic, immersive graphics
  • Low latency NVIDIA Reflex platform
  • NVIDIA Encoder: Designed for live streaming
  • NVIDIA Broadcast: AI-powered video and voice
  • NVIDIA Studio: Accelerate Your Creativity
  • NVIDIA Omniverse: Collaboration Platform for 3D Design
  • NVIDIA DLSS 3: AI Accelerated Performance


Ray tracing

Hyper-realistic and hyper-fast, Ray tracing brings you as close to reality as possible. Ada architecture harnesses the full power of ray tracing, which simulates the behaviour of light in the real world. Thanks to the power of the RTX 40 series GPUs and third-generation RT cores, you can enjoy virtual worlds that are more detailed than ever.

NVIDIA DLSS 3

Multiply your performance with AI. A revolutionary innovation in AI-based graphics rendering, DLSS greatly accelerates gaming performance. Powered by the fourth-generation Tensor cores and Optical Flow Accelerator of GeForce RTX 40 series GPUs, DLSS 3 uses AI to generate additional high-quality images.

NVIDIA Reflex


Victory is measured in milliseconds. GeForce RTX 40 series GPUs and NVIDIA Reflex technology deliver the lowest latency and best responsiveness to give you the ultimate competitive advantage. Designed to optimize and measure your system's latency, NVIDIA Reflex technology accelerates target acquisition, minimizes reaction times, and improves accuracy in competitive gaming.

NVIDIA Studio

Your ideas, accelerated by NVIDIA Studio. Take your creative projects to the next level with NVIDIA Studio. Optimised with new dedicated hardware, RTX 40 series graphics cards give you unrivalled performance for 3D rendering, video editing and graphic design. Take advantage of RTX's unprecedented acceleration capabilities in industry-leading creative applications, state-of-the-art NVIDIA Studio drivers designed for maximum stability, and the latest NVIDIA graphics technology.and an exclusive suite of tools that harness the power of RTX to accelerate AI-assisted creative workflows.

Specifications
Select your criteria

General information

Product name

Gigabyte GeForce RTX 4080 SUPER WINDFORCE OC V2 16G

Brand

Gigabyte

Model

GV-N408SWF3V2-16GD

Graphics chipset

Graphics chipset

NVIDIA GeForce RTX 4080 SUPER

GPU brand

NVIDIA

Overclocked

Yes

Number of GPU

1

Bus

PCI Express 4.0 x16

Memory

Video memory size

16 GB

Memory interface

256 bit(s)

Video memory frequency

23000 MHz

Memory type

GDDR6X

Architecture

Stream processors

10240

AI Ready

Yes

Direct X support (version)

12

Technical specifications

Multi-GPU

None

Display

Optimal in-game resolution

Up to 4K

HD Ready

Yes

4K UHD resolution(s)

Yes

VR Ready (virtual reality)

Yes

VirtualLink compatible

No

Connectivity

Video outputs

1 X HDMI Female
3 X DisplayPort Female

Number of monitor

4

HDMI standard

HDMI 2.1

DisplayPort standard

DisplayPort 1.4

Power connector(s)

1 X PCI Express 16 Pin (12VHPWR)

Design

Cooling type

Active (fansink)

Consumption

320 W

Low profile

No

Format

Dual Slot

Number of PCI slots

2.75

LED

No

LED RGB

No

Length

330 mm

Width

136 mm

Thickness

58 mm

Use

NVIDIA RTX Gamer

Warranties

Commercial warranty

Seller 3 years

Legal warranty

See terms & conditions

Product referenced on 8 Jan 2024

Customer reviews
  • 83%
    5 reviews
  • 17%
    1 review
  • 0%
  • 0%
  • 0%
  • by FlorianP
    Posted on 11 Oct 2024
    Bought on 11 Sep 2024 from LDLC
    Number of reviews: 2 Average rating: 10

    Comfort

    Pleasant, responsive power.
    The power management makes it economical with electricity and the high-performance ventilation means it's often in passive mode on small games. Comfort for your ears if you have the machine next to your screens.

    Review automatically translated
  • by Wonghienphilippe
    Posted on 17 Aug 2024
    Bought on 18 Jul 2024 from LDLC
    Number of reviews: 1 Average rating: 10

    Order RTX 4080 super graphics card

    I ordered my graphics card on LDLC.com on 17 July 2024. Chronopost delivery. parcel in perfect condition received on 24 July 2024. my card is working correctly.

    Review automatically translated
  • by luke
    Posted on 24 Apr 2024
    Bought on 26 Mar 2024 from LDLC
    Number of reviews: 1 Average rating: 10

    YES !!!!!!!!!

    At last my Reverb G2 is working as it should thanks to this card.
    It really does the job, and even though the price is still a bit high, I know that I won't be changing GPUs for another 4 or 5 years.

    Review automatically translated
  • by Olivier
    Posted on 13 Apr 2024
    Bought on 4 Apr 2024 from LDLC
    Number of reviews: 8 Average rating: 8

    Very good

    Excellent card with phenomenal power. However, it's impossible to turn on the LEDs as the card isn't detected by RGB FUSION. A bit frustrating for equipment at this price.

    Review automatically translated
  • by BadMofo
    Posted on 12 Mar 2024
    Bought on 2 Feb 2024 from LDLC
    Number of reviews: 1 Average rating: 10

    Great performance in 4k

    Very good card for 4k, with dlss and framegen we're on 100fps+.
    Doesn't get particularly hot, I'm very happy with it.

    Review automatically translated
