NZXT H5 Flow RGB White
Compact mid-tower case with tempered glass side window and RGB fans
Pictures may differ from actual products
The NZXT H5 Flow RGB is a modern PC Gaming case with a tempered glass side panel and 140mm RGB fans on the front. It has all the features you would expect from a PC Gaming case.
Compact mid-tower case with tempered glass side window and RGB fans
Case color:
Overview
RGB Mid Tower Gaming Case
The NZXT H5 Flow RGB is a modern Gaming PC case with a tempered glass side panel and 140mm RGB fans on the front. It has all the features you would expect from a gaming PC case: cooling performance, modularity, design and ample space for all components. The dark tempered glass and the two 140mm RGB Core F-series fans on the front give it a unique look.
High Performance AirFlow
The H5 Flow RGB is equipped with two pre-installed F140 RGB Core fans and two F120Q Quiet Airflow fans to keep this compact mid-tower really cool. With optimized thermal performance and intuitive cable management, the H5 Flow is an ideal chassis for most builds.- The dedicated fan on the bottom inner panel is angled to cool the graphics card
- Perforated front panel for optimal ventilation
- Intuitive cable management system with large channels, hooks and straps
- Tool-free access to front and side panels
- Front panel supports up to two 140mm fans or one 280mm radiator.
- Top panel supports up to two 120mm fans or one 240mm radiator.
- Includes two pre-installed F140 RGB Core fans and two F120Q Quiet Airflow fans
- Allows multiple F140 RGB Core fans to be connected to the 5V ARGB header on the motherboard
Generous interior space
This case is compatible with most NVIDIA GeForce RTX 40 series graphics cards thanks to its 400mm of free space. In addition, it has a heatsink support measuring up to 280 mm at the front, 240 mm in height and 120 mm at the back. Can accommodate up to 6 fans, including the dedicated CPU fan.
Specifications
Select your criteria
General information |
Product name |
NZXT H5 Flow RGB White |
Brand |
NZXT | |
Model |
CC-H51FW-R1 | |
Main characteristics |
Graphic card max. length |
365 mm |
Max height CPU fan |
165 mm | |
Power supply max. length |
185 mm | |
Power format |
ATX/EPS | |
Case format |
Mid tower | |
Use |
Gamer | |
| Office | ||
Material |
Steel | |
| Tempered glass | ||
Motherboard format |
ATX | |
| Micro ATX | ||
| Mini ITX | ||
Power supply supplied |
No | |
Design |
Case color |
White |
Front color |
White | |
Integrated display |
No | |
Glass |
Yes | |
Tempered glass |
Yes | |
Fish tank (panoramic view) |
No | |
LED RGB |
Yes | |
ARGB LED |
Yes | |
Water cooling compatible |
Yes | |
Motherboard connector location |
Standard connectors (on the motherboard) | |
Expansion slots |
Number of PCI slots |
7 |
Low profile |
No | |
Number of visible 3.5" slots |
0 | |
Number of invisible 3.5" slots |
1 | |
Number of 2.5" slots |
2 | |
Number of 2.5"/3.5" slots |
0 | |
Number of visible 5.25" slots |
0 | |
Number of Slot-in slim 5.25'' slots |
0 | |
Number of Slim 5.25'' slots |
0 | |
Front connectivity |
Location of expansion ports |
Top |
Connector(s) available |
1 X USB 3.0 | |
| 1 X USB 3.1 Type C | ||
| 1 X Headphone (3.5mm Jack Female) | ||
Cooling |
Fan(s) included |
Yes |
Number of rear fan(s) slots |
1 X 120mm | |
Quantity of rear fan(s) supplied |
1 | |
Number of front fan(s) slots |
2 X 120 or 140mm | |
Quantity of front fan(s) supplied |
2 | |
Number of above fan(s) slots |
2 X 120mm | |
Quantity of above fan(s) supplied |
0 | |
Number of underneath fan(s) slots |
1 X 120mm | |
Quantity of underneath fan(s) supplied |
1 | |
Water cooling |
AIO radiator compatibility |
120mm radiator |
| 240mm radiator | ||
| 280mm radiator | ||
| 140mm radiator | ||
Front AIO slot(s) |
120mm radiator | |
| 240mm radiator | ||
| 280mm radiator | ||
| 140mm radiator | ||
Above AIO slot(s) |
140mm radiator | |
| 240mm radiator | ||
| 120mm radiator | ||
Rear AIO slot(s) |
120mm radiator | |
Physical characteristics |
Width |
227 mm |
Height |
464 mm | |
Depth |
446 mm | |
Weight |
7.36 kg | |
Volume |
47 l | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
See all NZXT products
Product referenced on 4 May 2023
