I've got a heavy duty case for those who like Thermaltake and don't need a drive or anything else on the front panel.
I've put a 360 watercoling on the top and it's a good fit.
Thanks for the promotion at LDLC
If you've always dreamed of an efficient yet understated gaming case for your system, then look no further. With the S500 TG Snow, Thermaltake offers a mid-tower case that combines a spacious interior with plenty of options for your ATX, micro-ATX or mini-ITX setup and a no-frills, no-frills look, just a tempered glass side panel. With 400 mm of space for the graphics card (without HDD rack) and 172 mm for the cooling unit, the S500 TG Snow has enough room for the most powerful configurations of the moment. In terms of cooling, it has 7 slots for 120 mm fans and can also accommodate 140 or 200 mm models. Watercooling compatibility is also assured, as you can fit a maximum 420 mm radiator. All you have to do is install your hard drives and SSDs to get the most out of your new case!
The S500 TG Snow has been designed to be efficient and functional on a daily basis. Thus, you will have at your disposal no less than 7 fan slots (3 x 120/140 mm or 2 x 200 mm on the front with 1 x 140 mm supplied, 3 x 120, 2 x 140/200 mm on the top and 1 x 120 mm supplied on the back) with an advanced watercooling compatibility (maximum 420 mm radiator), certified Tt LCS.
When it comes to storage, you get up to 6 dedicated 2.5 slots, enough to keep all your favourite games and movies. With an optimised interior space, this case can be used as a base for the best configurations of the moment: 400 mm of space for the graphics card, 172 mm for the ventirad or even 220 mm for the power supply: treat yourself!
General information |
Product name |
Thermaltake S500 TG Snow |
Brand |
Thermaltake | |
Model |
CA-1O3-00M6WN-00 | |
Main characteristics |
Graphic card max. length |
282 mm |
Max height CPU fan |
172 mm | |
Power supply max. length |
220 mm | |
Power format |
ATX/EPS | |
Case format |
Mid tower | |
Use |
Gamer | |
Office | ||
Material |
Steel | |
PVC | ||
Tempered glass | ||
Motherboard format |
Mini ITX | |
Micro ATX | ||
ATX | ||
Power supply supplied |
No | |
Design |
Screwless fixing system |
No |
Case color |
White | |
Front color |
White | |
Dust filters |
1 | |
Glass |
Yes | |
Tempered glass |
Yes | |
LED RGB |
No | |
ARGB LED |
No | |
Water cooling compatible |
Yes | |
Expansion slots |
Number of PCI slots |
8 |
Low profile |
No | |
Number of visible 3.5" slots |
0 | |
Number of invisible 3.5" slots |
0 | |
Number of 2.5" slots |
2 | |
Number of 2.5"/3.5" slots |
3 | |
Number of visible 5.25" slots |
0 | |
Number of invisible 5.25" slots |
0 | |
Number of Slot-in slim 5.25'' slots |
0 | |
Number of Slim 5.25'' slots |
0 | |
Front connectivity |
Location of expansion ports |
Top |
Connector(s) available |
1 X Microphone (3.5mm Jack Female) | |
1 X Headphone (3.5mm Jack Female) | ||
2 X USB 2.0 | ||
2 X USB 3.0 | ||
Cooling |
Number of rear fan(s) slots |
1 X 120mm |
Quantity of rear fan(s) supplied |
1 | |
Number of front fan(s) slots |
2 X 200mm | |
3 X 120 or 140mm | ||
Quantity of front fan(s) supplied |
1 | |
Quantity of side fan(s) supplied |
0 | |
Number of above fan(s) slots |
2 X 140 or 200mm | |
3 X 120mm | ||
Quantity of above fan(s) supplied |
0 | |
Quantity of underneath fan(s) supplied |
0 | |
Water cooling |
AIO radiator compatibility |
360mm radiator |
420mm radiator | ||
280mm radiator | ||
240mm radiator | ||
140mm radiator | ||
120mm radiator | ||
Physical characteristics |
Width |
240 mm |
Height |
565 mm | |
Depth |
500 mm | |
Weight |
15.04 kg | |
Volume |
67.8 l | |
Warranties |
Commercial warranty |
Seller 2 years |
Legal warranty |
See terms & conditions |
See all Thermaltake products
Product referenced on 27 Dec 2019
I've got a heavy duty case for those who like Thermaltake and don't need a drive or anything else on the front panel.
I've put a 360 watercoling on the top and it's a good fit.
Thanks for the promotion at LDLC
I bought this case on 70% off sale and I can see why... I received it and the top of the case is all bent. It should have been stated that this was the case. I probably wouldn't have bought it
Excellent box to replace a Fractal Meshify C which was very efficient but a bit too noisy. This case is spacious, making it easy to assemble and the different openings allow for efficient cable management. A Be Quiet Pure Rock 2 fan, a 6700XT and 6 fans fit with room to spare. The hardware supplied is very complete (motherboard installation, fans, SSD and 2 3.5" drives).
I would have liked a riser (not supplied) to take advantage of the supports and rubber to limit the vibration of the 3.5" disks. Otherwise, the internal connectivity is fine. Very good case for mounting large components.
