The MSI MPG VELOX 100R is a beautifully designed Gaming PC case capable of accommodating the latest generation configurations. The design features a tempered glass panel and four 120mm fans (three on the front and one ARGB on the back).
Medium gaming tower case with tempered glass window and 1 ARGB fan
The MSI MPG VELOX 100R is a beautifully designed gaming PC case capable of accommodating the latest generation configurations. The design features a tempered glass panel and four 120 mm fans (three on the front and one ARGB on the back). Its design and numerous options make it particularly efficient for cooling the most powerful systems.
Select your criteria
General information |
Product name |
MSI MPG VELOX 100P AIRFLOW |
Brand |
MSI | |
Model |
306-7G18P25-809 | |
Main characteristics |
Graphic card max. length |
380 mm |
Max height CPU fan |
175 mm | |
Power supply max. length |
220 mm | |
Power format |
ATX/EPS | |
Case format |
Mid tower | |
Use |
Gamer | |
Material |
Steel | |
| Plastic | ||
| Tempered glass | ||
Motherboard format |
ATX | |
| Micro ATX | ||
| Mini ITX | ||
Power supply supplied |
No | |
Design |
Screwless fixing system |
No |
Case color |
Black | |
Front color |
Black | |
Dust filters |
2 | |
Integrated display |
No | |
Glass |
Yes | |
Tempered glass |
Yes | |
Fish tank (panoramic view) |
No | |
LED RGB |
Yes | |
ARGB LED |
Yes | |
Water cooling compatible |
Yes | |
Motherboard connector location |
Standard connectors (on the motherboard) | |
Expansion slots |
Number of PCI slots |
7 |
Low profile |
No | |
Number of visible 3.5" slots |
0 | |
Number of invisible 3.5" slots |
2 | |
Number of 2.5" slots |
2 | |
Number of 2.5"/3.5" slots |
0 | |
Number of visible 5.25" slots |
0 | |
Number of invisible 5.25" slots |
0 | |
Number of Slot-in slim 5.25'' slots |
0 | |
Number of Slim 5.25'' slots |
0 | |
Front connectivity |
Location of expansion ports |
Top |
Connector(s) available |
Headphone (3.5mm Jack Female) | |
| Microphone (3.5mm Jack Female) | ||
| 2 X USB 3.0 | ||
| 1 X USB 3.2 Type C | ||
Cooling |
Fan(s) included |
Yes |
Number of rear fan(s) slots |
1 X 120mm | |
Quantity of rear fan(s) supplied |
1 | |
Number of front fan(s) slots |
3 X 120 or 140mm | |
Quantity of front fan(s) supplied |
3 | |
Number of side fan(s) slots |
2 X 120mm | |
Number of above fan(s) slots |
2 X 140mm | |
| 3 X 120mm | ||
Water cooling |
AIO radiator compatibility |
360mm radiator |
| 280mm radiator | ||
| 240mm radiator | ||
| 140mm radiator | ||
| 120mm radiator | ||
Front AIO slot(s) |
280mm radiator | |
| 240mm radiator | ||
| 140mm radiator | ||
| 120mm radiator | ||
| 360mm radiator | ||
Above AIO slot(s) |
120mm radiator | |
| 140mm radiator | ||
| 240mm radiator | ||
| 280mm radiator | ||
| 360mm radiator | ||
Rear AIO slot(s) |
120mm radiator | |
Physical characteristics |
Width |
231 mm |
Height |
490 mm | |
Depth |
474 mm | |
Weight |
10 kg | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
See all MSI products
Product referenced on 1 Jun 2022
Plenty of space, management cable already in place, no need to activate the RGB which I simply didn't plug in, more than adequate fans supplied, welcome filters, operating indicators, USB sockets and, what's more, a good metal finish.
The HDD rack is badly oriented and the HDD heats up for nothing.
Beautiful case, very practical and looks great on my desk ^^. I highly recommend it.
I was looking for a case big enough to hold an RTX 4070 TI with AIO watercooling. This was the very first case I bought. It's quite imposing and quite heavy.
The case comes with four fans already attached (one at the rear, three at the front). I don't think it's possible to completely remove the base at the top. However, you can remove a sort of magnetised plate to make the ventilation go through better, and also aim for the potential watercooling at the top. (If you're fitting 360 watercooling, don't forget to unscrew the front fan at the top of the front panel by unclipping the front panel: you'll then have enough space to pass the radiator and your fans through. Otherwise it won't fit with the fans fitted as standard).
Be careful with the cable management though, if you don't do it right, you'll have trouble fitting an imposing CG like the 4070TI.
I think it's a good case with good ventilation and plenty of space for the latest configurations.
