Matrox C680 (C680-E4GBF)

4 GB GDDR5 - 6 miniDP - PCI Express 3.0 x16

Last price 899€95
Holy Moly!
Overview

Drive up to 6 displays with one card

The Matrox C680 graphics card has 6 mini DisplayPort outputs to drive as many displays or projectors. You get a maximum resolution of 4096 x 2160 per miniDP output. The Matrox C680 is a dedicated card designed to drive video walls with up to 6 displays. Operating in extended desktop mode, it provides a single hyper-wide surface on all connected displays. It is an ideal solution for digital signage/presentation and video wall applications. The Matrox C680 board provides a cost-effective video wall solution for installations in corporate, industrial, pro A/V, digital signage, security, control, and other applications.

Drive your displays easily

With the Matrox C680, you can drive up to six synchronized displays or projectors from a single board. You minimize power consumption because the C680 is highly energy efficient, requiring only 50W to support your six display devices. With PowerDesk software you can customise your installation by configuring your multi-display and managing your desktop. You can either produce consistent and continuous images across multiple screens with frame management or clone content to display the same information on all screens.

Key features:

  • Drive up to six displays or projectors with a maximum resolution of 6x 4096 x 2160 @ 30 Hz or 3x 4096 x 2160 @ 60 Hz in mini DP
  • RAM: 4 GB GDDR5
  • Supports DirectX 12, OpenGL 4.4 and OpenCL 1.2
  • Advanced EDID management
  • Low power consumption of 50W
  • Compatible with Windows 10 / 8.1 / 7, Windows Embedded Standard 7, Server 2012 R2 (64) / 2008 R2 (64), Linux
Specifications
Select your criteria

General information

Product name

Matrox C680 (C680-E4GBF)

Brand

Matrox

Model

C680-E4GBF

Graphics chipset

Graphics chipset

Matrox C680

Number of GPU

1

Bus

PCI Express 3.0 x16

Memory

Video memory size

4 GB

Memory type

GDDR5

Applications

Multi-GPU

None

Use

Multi-Display

OpenGL support

OpenGL 4.4

Direct X support (version)

12

GPGPU

OpenCL 1.2

Display

Dual monitor

Yes

HD Ready

Yes

TV tuner

No

Connectivity

Video outputs

6 X Mini DisplayPort

Design

Cooling type

Active (fansink)

Consumption

50 W

Low profile

No

Format

Single Slot

Power connector(s)

None

Length

167.6 mm

Warranties

Commercial warranty

Seller 2 years

Legal warranty

See terms & conditions

Product referenced on 23 Oct 2020
